225 / 720
-
200 / 40
Card capacities
Up to 200 card input / 40 card output -
3 YEAR
Warranty
3-year warranty on printer and 2-year warranty on printhead -
Up to 1200dpi
Prining resolution
300dpi (Color & Mono), 600 & 1200dpi (Mono only) -
Operating systems
Windows and Mac OS compatible
Specifications
PRINTING
- Print Mode: Single Sided / Dual Sided
- Print Type: Direct Dye-Sublimation
- Print Area: Edge to Edge
- Resolutions: 300dpi (Color & Mono), 600 & 1200dpi (Mono only)
- Dual Side Printing: Option (with Flipper)
CARD
- Card Feeding: Automatic
- Card Size: ISO CR80 or ISO CR79 (Option-Factory installed)
- Card Thickness: 0.38mm (15mil) ~ 1.0mm (40mil)
- Card Type: PVC, PET, Composite PVC
PRINT SPEED
- Monochrome: 5 sec./card (720 cards/hour)
- YMCKO: Max. 17 sec./card (212 cards/hour)
- YMCKOK (Dual Sided printers): Max. 22 sec./card (164 cards/hour)
LAMINATING (For Laminating Printer)
- Mode: Single & Dual
- Film (Clear & Holographic): 0.6mil, 1.0mil
- Speed (Simultaneous): 22 sec./card (YMCK, Single Lamination)
- Speed (Simultaneous): 32 sec./card (YMCKK, Single Lamination)
- Speed (One by One): 43 sec./card (YMCK, Single Lamination)
- Speed (One by One): 53 sec./card (YMCKK, Single Lamination)
CAPACITY
- Input Hopper: Card: 100 Cards / 200 Cards with cover open
- Output Hopper: Card: Front : 40 Cards / Rear : 100 Cards (Optional Rear-side Stacker)
SYSTEM
- Memory: 64MB RAM
- Interface: 2 Line LCD / 2 LED Buttons
- Supported Platforms: Microsoft Windows 7/ 8 /10, Mac OS, Linux
- Communication:USB, Ethernet, WiFi (Option)
- Power Supply: Free Voltage (AC 100/ 220V, 50~60Hz)
- Power Consumption: 48W / 96W (Laminating Printer)
- Temperature: 15~35°
- Humidity: 35~70%
SECURITY
- Physical Lock: Input Hopper & Ribbon (Option)
- Station Itself: Kensington Lock (Option)
DIMENSIONS
- Milimeter:
- Single: 165 (W) x 390 (L) x 210 (H)
- Dual: 165 (W) x 498 (L) x 210 (H)
- Laminating: 165 (W) x 675 (L) x 210 (H)
- Inch:
- Single: 6.5 (W) x 15.4 (L) x 8.3 (H)
- Dual: 6.5 (W) x 19.6 (L) x 8.3 (H)
- Laminating: 6.5 (W) x 26.6 (L) x 8.3 (H)
WEIGHT
- Single: 4.5 kg/ 10 lbs
- Dual: 5.2 kg/ 11.5 lbs
- Laminating: 8.8 kg/19.4 lbs (Approx)
ENCODING OPTION
- Magnetic: ISO 7811 (Track I, II, III Read/ Write, HiCo/ LoCo), JIS II
- Contact: ISO 7816 A/B/C Card, ISO 7816 1/2/3/4 Microprocessor Card
- Contactless: ISO 14443 (Type A/ B), MIFARE, DESFIRE, iCLASS, ISO 18092(NFC), Felica
CERTIFICATIONS
- Certifications: CB, CE, FCC, KC, CCC
