150
-
100 / 200
Card capacities
100 card input / 200 card output -
3 YEAR
Warranty
Printer - 3 years including one year of free printer loaner support Printhead - Lifetime; unlimited pass -
256
Colors
Up to 16.7 million /
256 shades per pixel -
Operating systems
Windows and Mac OS compatible
Specifications
Print Method
HDP Dye-Sublimation / Resin Thermal Transfer
Resolution
300 dpi (11.8 dots/mm)
Colors
Up to 16.7 million / 256 shades per pixel
Print Speed (batch mode)**
- up to 24 seconds per card / 150 cards per hour (YMC with transfer)*
- up to 29 seconds per card / 124 cards per hour (YMCK with transfer)*
- up to 40 seconds per card / 90 cards per hour (YMCKK with transfer)*
- up to 35 seconds per card / 102 cards per hour (YMCK with transfer and dual-sided, simultaneous lamination)*
- up to 48 seconds per card / 75 cards per hour (YMCKK with transfer and dual-sided, simultaneous lamination)*
Accepted Standard Card Sizes
CR-80 (3.370˝ L x 2.125˝ W / 85.6 mm L x 54 mm W)
Accepted Card Thickness
.030˝ (30 mil) to .050˝ (50 mil) / .762 mm to 1.27 mm
Input Card Cartridge Capacity
100 cards (.030˝ / .762 mm)
Output Hopper Card Capacity
200 cards (.030˝ / .762 mm)
Software Drivers
- Windows 8/ 7/ Vista (32bit & 64 bit) / Server 2008 & 2003/ XP;
- Mac OS X v10.6 / v10.5 & Linux***
Print Area
Over-the-edge on CR-80 cards
Warranty
- Printer - Three years including one year of free printer loaner support (U.S. only); optional Extended Warranty Program (U.S. only)
- Printhead - Lifetime; unlimited pass
Options
- Dual card input hopper
- Card lamination module – single-sided or dual-sided (simultaneous)
- Smart card encoding (contact/contactless)
- Dual-sided printing
- Door and cartridge locks
- Printer cleaning kit
- Magnetic stripe encoding
- Secure Proprietary Consumables System
- Custom Secure Holographic HDP Film and Overlaminate
Included Software
FARGO Workbench Diagnostic Utility with Color Assist spot-color matching
